Nocpix ACE Thermal Imaging Scopes

The ACE series of thermal scopes is the Nocpix flagship scope for all hunting environments.

The ACE H50R features superior performance and image quality to meet the needs of professional hunters. This scope provides excellent image processing speed combined with a rapid refresh rate to provide a snappy and responsive image.

The ACE H50R offers 1x-3x Optical- and 3x-8x Digital-magnification, for a 3x-24x practical magnification range. It boasts a crisp 1.03" 2560x2560 AMOLED screen, and a 50mm F0.9 objective lens.

The ACE S60R brings the flagship top of the line performance with the highest resolution sensor core offered by Nocpix at 1280x1024 paired with a larger objective lens. This provides incredible detail, even at extreme distances.

Both models feature an integrated laser range finder.

Compatible with a wide variety of 30MM scope mounts including the Unity Tactical LPVO and REKE series.

Specs:

H50R:
Detector: 640x512, 12μm
Lens: F0.9 50mm
Human detection: 2600m
NETD: ≤15mK
Frame Rate: 60Hz
FOV: 8.8°x7.0°
Range Finder: Yes
Diopter compensation: -5 to +5 dpt
Optical Zoom: 1x-3x
Electronic Zoom: 3x-8x
Total Zoom: 3x-24x
Battery life: ≥ 7h
Battery type: Built-in 4000 mAh battery + replaceable 18650 battery
Display: 2560x2560 AMOLED
Storage: 64 GB
Recoil proof: Yes, up to 6000 J
Mounting options: Direct aim
Compatible mount: 30mm tube
Weight: 1120g

S60R:
Detector: 1280x1024, 12μm
Lens: F1.0 60mm
Human detection: 3100m
NETD: ≤15mK
Frame Rate: 50Hz
FOV: 14.7°x11.7°
Range Finder: Yes
Diopter compensation: -5 to +5 dpt
Optical Zoom: 1x-3x
Electronic Zoom: 2x-8x
Total Zoom: 2x-24x
Battery life: ≥ 6h
Battery type: Built-in 4000 mAh battery + replaceable 18650 battery
Display: 2560x2560 AMOLED
Storage: 64 GB
Recoil proof: Yes, up to 6000 J
Mounting options: Direct aim
Compatible mount: 30mm tube
Weight: 1300g
