The Nocpix S75R a next generation 1280 x 1024 thermal monocular/scope that is adapted for use as a dedicated weapon sight with reticle. These are the newest and highest resolution thermal sights available on the commercial market.
Instead of being an expensive CR123 munching machine, this thermal weapon sight uses an on board quick switch power supply, similar to those used by hand tools. A spare battery is included in the package as well.
It includes a laser range finding capability able to range accurately out to 1200m and a fast refresh rate to enable smooth tracking of targets.
| MODEL | RS75 |
| Type | Uncooled |
| Resolution, pixels | 1280×1024 |
| Pixel Size, um | 12 |
| NETD, mk | ≤15 |
| Frame Rate, Hz | 60 |
| Optical Characteristics | |
| Objective Lens, mm | 75 F1.0 |
| Field of View, º | 11.7×9.4 |
| Magnification, x | 3× |
| E-zoom, x | 3-30x |
| Eye Relief, mm | 70 |
| Display | |
| Type | OLED |
| Resolution, pixels | 2560×2560 |
| Operational Characteristics | |
| Battery | 4400mAh |
| Max. Operating Time (at temp.=22 ºC), h* | 4.5h |
| External power supply | 5V (Type C USB) |
| Max. Recoil Power on Rifled Weapon, g/s² | 1000 |
| Degree of protection, IP code | IP67 |
| Amount of built-in memory, GB | 128 |
| Operating Temperature Range, ℃ | -20~+50 |
| Weight, g | ≤1200g |
| Dimension, mm | 342×116×93 |
| USB Interface | Type-C |
| Detection Range, m (Target size:1.7m×0.5m, P(n)=99%) | 3896 |
Included accessories
- Padded Hard Case
- Extra Battery
- Laser Range Finder
- Charger and charging accessories
- Picatinny weapon mount
This product is export controlled, but we do export! Please contact us prior to ordering for more information on the export process.
Origin:
Manufactured in China
